| Serial Number |
Item |
Indoor P2 spherical display screen with a diameter of 0.61 meters |
| 1 |
Pixel composition |
Arrangement form |
 |
| 2 |
Pixel tube spacing |
2mm |
| 3 |
Emitting point color |
1R1G1B |
| 4 |
LED |
SMD1212 |
| 5 |
Composition of primary colors |
RGB |
| 6 |
Module |
The number of module types |
3 types |
| 7 |
Cabinet |
Beer-themed LED Screen |
 |
| 8 |
Display area |
2.7 square meter |
| 9 |
Power supply |
Input Voltage(AC) |
220V±10% 50/60HZ |
| 10 |
SPS |
5V/40A /200W |
| 11 |
Ground Leakage Current |
< 3mA |
| 12 |
Pmax |
≤2400W |
| 13 |
Power supply |
Average Power |
350W |
| 14 |
Control system |
Control host operating system |
Computers with WIN2000, XP, WIN7 + control software hardware + playback software and hardware |
| 15 |
Control mode |
Synchronous control |
| 16 |
Control system |
Heterogeneous system |
| 17 |
Main Technical Parameters |
LED driver |
Constant current drive |
| 18 |
Refresh rate |
≥3840HZ |
| 19 |
Display color |
Display ≥16.7M colors |
| 20 |
Gray scale |
≥14BIT |
| 21 |
Sphere resolution |
Width 1872 × Height 958 points |
| 22 |
Full screen brightness |
≥600cd/m² |
| 23 |
Frame change speed |
60 frames per second |
| 24 |
Color temperature |
8500K (customizable according to customer requirements) |
| 25 |
Out-of-control point |
≤1/10000 and discretely distributed |
| 26 |
Optimal viewing distance |
2~10M |
| 27 |
Viewing angle |
Horizontal 160°, vertical 160° |
| 28 |
Flatness |
<1MM |
| 29 |
Color difference |
Color difference consistency |
| 30 |
Luminance Uniformity |
The brightness deviation across the entire screen does not exceed 5%. |
| 31 |
Environmental temperature |
-20°C~60°C |
| 32 |
Relative humidity |
10%~95% non-condensing |
| 33 |
Service life |
Over 100,000 hours |
| 34 |
Mean time between failures (MTBF) |
≥5000 hours |
